Fuel Flow Meters

Overview

Fill-Rite 901 Series meters are three-digit mechanical registers capable of measuring in gallons (Gal) or liters (L) depending on the model. Built from durable aluminum or nickel-plated aluminum housings, these meters deliver consistent performance for a broad range of fueling applications, including agricultural, fleet, and industrial refueling.

Key Models & Configuration

Model Description Flow Range (GPM / LPM) Max Pressure (PSI / bar) Inlet/Outlet Body Material Seal Material Compatible Fluids
901C 3-digit (Gal) 5–20 / 19–75 50 / 3.5 1″ / 1″ NPT Aluminum Viton® & Buna Gasoline, Diesel, B20, E15, Kerosene
901CL 3-digit (L) 5–20 / 19–75 50 / 3.5 1″ / 1″ NPT Aluminum Viton® & Buna Gasoline, Diesel, B20, E15, Kerosene
901C1.5 3-digit (Gal) 5–20 / 19–75 50 / 3.5 1½” / 1½” NPT Aluminum Viton® & Buna Gasoline, Diesel, B20, E15, Kerosene
901CL1.5 3-digit (L) 5–20 / 19–75 50 / 3.5 1½” / 1½” NPT Aluminum Viton® & Buna Gasoline, Diesel, B20, E15, Kerosene
901CN1.5 3-digit (Gal) 5–20 / 19–75 50 / 3.5 1½” / 1½” NPT Nickel-Plated Aluminum Viton® Non-Potable Water (plus fuels)

Key Features & Benefits

  • Rugged Mechanical Design: No electronic components; purely mechanical register for reliable operation in remote or harsh environments
  • Easy-to-Read Meter Face: Large, 3-digit roller counter for straightforward batch measurements
  • Simple Maintenance: Field-serviceable internal components with accessible calibration points for quick flow adjustment
  • Versatile Fluid Handling: Broad chemical compatibility for petroleum fuels and select water-based fluids
  • Compact Form Factor: Easy integration with pump units, fueling nozzles, or inline mounting with minimal space requirements

Typical Applications

  • Farm & Fleet Fuel Transfer: Diesel tanks, tractors, heavy machinery fueling
  • Commercial Fuel Pumps: Gasoline dispensing in small-scale distribution setups
  • Construction & Mining: On-site fueling stations for heavy equipment (within stated flow/pressure specs)
  • Non-Potable Water: Select models for irrigation, dust control, or industrial water transfer
  • Portable Transfer Tanks: Installation on mobile fuel trailers or service trucks

Technical Specifications

Parameter Details
Flow Rate 5–20 GPM (19–75 LPM) Suited for low-to-mid flow transfer in fueling, bulk plant, or farm applications
Maximum Working Pressure 50 PSI / 3.5 bar Adequate for standard transfer pump setups or gravity feed systems
Materials Body: Aluminum or nickel-plated aluminum Seals: Viton® or Buna Internals: Stainless steel, polyester, PPS
Display & Register 3-Digit Mechanical: Resets to zero for each batch Units: U.S. gallons (“Gal”) or liters (“L”)
Accuracy & Calibration Typically ±2% of reading under normal flow conditions Adjustable calibration screws for on-site fine-tuning
Operating Temperatures -20°C to +60°C (approximate) Verify fluid temperature compatibility
