PVC Ball Valves are a popular choice for controlling flow in water, chemical, and light industrial applications. Their non-corrosive, lightweight design makes them suitable for a broad range of environments—from residential plumbing to commercial fluid systems. The True Union configuration allows for quick disassembly, making maintenance and valve replacement especially convenient.
Potable water systems, swimming pools, hot tubs, and HVAC lines. Easy-to-use shutoff or flow control in both indoor and outdoor installations.
Controlling water flow to fields, drip lines, or livestock water supplies. Corrosion-resistant performance for fertilizer lines or mild chemicals.
Suitable for mild chemical transfer where PVC compatibility is verified. Smooth internal bore for minimal pressure drop in process lines.
Saltwater aquariums, fish hatcheries, or brackish environments. PVC’s chemical resistance ensures longevity in marine conditions.
Removable End Connectors: Both ends can be unscrewed or disconnected for easy valve maintenance or replacement without reworking the entire pipeline. Replaceable Seals & Seats: Extends service life and reduces downtime.
Significantly lighter than metal valves, simplifying handling and installation. PVC material inherently resists rust, scale, and chemical deterioration.
Available in Socket (solvent weld) or Threaded (NPT/BSPT) variations to fit international standards: ASTM, JIS, DIN, CNS, etc. Can be glued or screwed into place, suiting different regional norms and system requirements.
Rated up to PN10 / PN16 (10–16 bar), making them robust enough for moderate-pressure fluid systems. Operable in typical temperature ranges for PVC (0°C to ~60°C) depending on operating environment and media.
| Valve Type | True Union Ball Valve (Socket Ends) |
| Size Range | 1/2" – 6" |
| Color | White, Ivory White |
| Connection | Screw (NPT/BSPT threads) or Glue (Socket Solvent Weld) |
| Pressure Rating | PN10 / PN16 (10–16 bar) |
| Standards | ASTM, JIS, BSPT, CNS, DIN |
| Material | Rigid PVC Body, EPDM or PTFE Seals (varies by model) |
| Temperature Range | ~0°C to +60°C (ambient) |
| Certification | ISO9001, CE |
| Features | High Quality, Long Life, Low Maintenance |
